产品型号 | STC-8105LC | STC-8156LC | STC-8210LC | STC-5102LC |
![]() | ![]() | ![]() | ![]() | |
重量 | 270g (0.60lb) | 620g (1.37lb) | 850g (1.87lb) | 360g (0.79lb) |
尺寸 | 124mm*63mm*34mm (0.41inch*0.21inch*0.11inch) | 178mm*40mm*76mm (0.58inch*0.13inch*0.29inch) | 195mm*80mm*46mm (0.64inch*0.26inch*0.15inch) | 130mm*66mm*38mm (0.43inch*0.22inch*0.13inch) |
冷却方式 | 自然冷却 | 自然冷却 | 自然冷却 | 自然冷却 |
防水 | IPX4 | IPX4 | IPX4 | IPX4 |
外壳材料 | Sabic PC945 | Sabic PC945 | Sabic PC945 | Sabic PC945 |
额定输入电压 | 110-240V | 110-240V | 110-240V | DC 12V |
额定输出电压 | 36V | 36V | 36V | 36V |
额定输出电流 | 3A | 4A | 6A | 2A |
最大输出电压 | 42V | 42V | 42V | 42V |
效率 | 110V>92% 220V>94% | 110V>92% 220V>94% | 110V>92% 220V>94% | ~93% |
