产品型号 | STC-5102LB | STC-5102LC | STC-5102LD | STC-8091LD |
![]() | ![]() | ![]() | ![]() | |
重量 | 360g (0.79lb) | 360g (0.79lb) | 360g (0.79lb) | 220g (0.49lb) |
尺寸 | 130mm*66mm*38mm (0.43inch*0.22inch*0.13inch) | 130mm*66mm*38mm (0.43inch*0.22inch*0.13inch) | 130mm*66mm*38mm (0.43inch*0.22inch*0.13inch) | 130mm*60mm*27mm (0.43inch*0.20inch*0.09inch) |
冷却方式 | 自然冷却 | 自然冷却 | 自然冷却 | 自然冷却 |
防水 | IPX4 | IPX4 | IPX4 | IPX4 |
外壳材料 | Sabic PC945 | Sabic PC945 | Sabic PC945 | Sabic PC945 |
额定输入电压 | DC 12V | DC 12V | DC 12V | 110-240V |
额定输出电压 | 24V | 36V | 48V | 12V |
额定输出电流 | 3A | 2A | 2A | 可调节 |
最大输出电压 | 25.2V | 42V | 58.8V | N/A |
效率 | ~93% | ~93% | ~93% | 110V>92% 220V>94% |
